Multi Function PLC Automatic Cosmetic Packing Machine For Food Pellet Cream Chemical
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | Weidong |
| Certification: | CE&ISO9001 |
| Model Number: | WDB-16 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | USD 8960/set |
| Packaging Details: | wood case |
| Delivery Time: | 5-7 work days |
| Payment Terms: | T/T |
| Supply Ability: | 10 Set/Sets per Month |
|
Detail Information |
|||
| Type: | Multi-Function Packaging Machine | Application: | Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles |
|---|---|---|---|
| Voltage: | 380V | Dimension(L*W*H): | 760 X 600 X 1650 Mm |
| Machinery Test Report: | Provided | Capacity: | Adjustable |
| Function: | Filling, Wrapping, Labeling, Laminating, Capping, Contain, Sealing,Boxing, Embossing,Gluing, Slitting | Core Components: | Motor, Pressure Vessel, Pump, PLC, Gear, Bearing |
| Highlight: | PLC Automatic Cosmetic Packing Machine,Multi Function Automatic Cosmetic Packing Machine |
||
Product Description
Automatic Cosmetic Packing Machine For Food, Pellet, Cream And Chemical Cosmetics
Product Discription:
1. This machine can automatically complete following work: solenoid valve control flow measuring--coding (optional)--bag making--filling--sealing--counting.
2. Computer/PLC control system, photoelectric tracking, maximizes the whole machine's control precision, reliability and the intellectualized degree.
3. Has fault display system, easy to operate and maintenance.
4. Machine body and all food touching part are made by stainless steel.
Features:
1.The whole body 304 stainless steel high-precision structure, rust and durable, easy operation and maintenance.
2.PLC, touch screen, stepper motor control, bag length set convenient and accurate.
3.Frequency control, bag more convenient and smooth, simple and quick, save time and film.
4.High sensitivity photoelectric eye color mark tracking, digital input sealing and cutting position, so that the sealing and cutting position more accurate.
5.Temperature independent PID control, better adapt to a variety of packaging materials.
6.From filling, bagging, printing date, inflatable (exhaust) one-time completion.
7.Drive system is simple, more reliable, more convenient maintenance.
8.All controls are implemented by software to facilitate functional adjustment and technology upgrades, never lagging behind.
Technical parameter:
| Measurement method | Screw measurement |
| Tank volume | 50L |
| Equipment material | 304 stainless steel in contact with material |
| Filling range | 100-1000grams |
| Filling accuracy | ±1% |
| Filling speed | 10-30 times/min |
| Circuit control | PLC control |
| Electricity source | 220V |
| Whole machine power | 0.9KW |
| Whole machine weight | 120KG |
| Whole machine volume | 800*220*1800MM |
Application:
It is suitable for the quantitive packaing of powder materials in the food,medicine,biology,chemical and other industries,such as medicines, milk powder,soy milk,health food,seasoning,mask powder,animal medicine(powder) etc.
