Doypack Filling And Capping Machine 304 Stainless Steel Automatic Filling Machine

Doypack Filling And Capping Machine 304 Stainless Steel Automatic Filling Machine

Product Details:

Place of Origin: Guangzhou
Brand Name: Weidong
Certification: CE & ISO9001

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 10-15 work days
Payment Terms: T/T
Supply Ability: 30 set per month
Get Best Price Contact Now

Detail Information

Condition: New Weight: About 1500Kg
Driven Type: Pneumatic Dimension(l*w*h): 2450×1200×1550(mm)
Warranty: 1 Year Function: Filling And Capping
Power Supply: 220V 50Hz
Highlight:

Doypack Filling And Capping Machine

,

Automatic Filling And Capping Machine

,

304 Stainless Steel Automatic Filling Machine

Product Description

Doypack Filling And Capping Machine 304 Stainless Steel

Description:

Use servo motor piston pump to fill, suitable for all kinds of water-based liquid, high precision; The structure of the pump adopts quick connection type disassembly mechanism,Easy to clean and disinfect.





Specification:

Applicable bottle size 20-200ML
Filling head 6 heads
Material 304 stainless steel (part in contact with material)
Loading error ±1% standard loading
Capping pass rate ≥ 98%
Power supply 220V 50Hz
Electrical power ≤2.2Kw
Compressed air pressure 0.4~0.6Mpa
Weight About 1500Kg
Dimensions 2450×1200×1550(mm)
Production capacity 1800-2400 bags/hour


Feature:

  1.  Silicone rubber, tetrafluoroethylene or other materials are used according to the different industry and liquid composition, and ceramic materials are used in special occasions.
  2. PLC control system, frequency control, high degree of automation.
  3.  Easy to adjust the amount of filling, can adjust all the filling amount at one time, can also be adjusted for each small amplitude; Easy to operate, adjust quickly.
  4. The filling needle is designed with a drip prevention device. When filling, it can be submerged into the bottom of the bottle and rise slowly to prevent foaming
  5.  The whole machine can be used for different specifications of bottles, easy to adjust, can be completed in a short time.
  6. The whole machine is designed according to GMP requirements.

Doypack Filling And Capping Machine 304 Stainless Steel Automatic Filling Machine 0Doypack Filling And Capping Machine 304 Stainless Steel Automatic Filling Machine 1Doypack Filling And Capping Machine 304 Stainless Steel Automatic Filling Machine 2







1. Why choose us?

1.1- We have over 20 years experience on machinery making .

1.2- Our factory is located in Guangzhou and another one is in Jiangsu province,more than 100 workers in our factory.

1.3- We sale good quality machines around the world with good service and got high reputation from our customer. Welcome to visit our factory!



2,I'm new in our industry, but I'm planing to set up a factory, what can I do ?

We will design the most suitable proposal based on your actual situation, such as the daily production, raw material formula, factory layout, etc. Also we would like to introduce some excellent suppliers of raw materials, bottles, labels, etc if needed. After sales,engineer will be send to fields installation , training and commissioning



3.Can you customize machine ?

As a professional machinery manufacturer for more than 20 years,we have skilled OEM technique.



4. What about after sale service?

Engineer will go to buyer's factory to install, test machines, and train buyer's staff how to operate, maintain machines. When machine has problem, We will solve basic questions by telephone, email, whatsapp, wechat and video call. Customers showing us the picture or video of the problem. If the problem can be easily solved , we will send you solution by video or pictures. If the problem out of your control, we will arrange engineer to your factory.



5.How about warranty and spare parts?

We provide 1.5 year warranty and enough spare parts for the machine,and most of the parts can be found in local market also,also you can buy from us if all the parts that over than 1.5 year warranty.



6. How can you control the quality and delivery?

All our machines will be tested before packaging. Teaching video and packing pictures will be sent to you for checking,we promise that our wooden packaging is strong enough and safety for long delivery .



7. What about the delivery time?

In stock machine:1-7days Usually 7-60 Working days(depened on products).
