304 Stainless Steel Filling Capping Labeling Machine Fully Automatic For Bottle
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | Weidong |
| Certification: | CE&ISO9001 |
| Model Number: | WD-bl660 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | $4800~$5000/set |
| Packaging Details: | Wooden case |
| Delivery Time: | 5-7 work days |
| Payment Terms: | T/T |
| Supply Ability: | 30 set per month |
|
Detail Information |
|||
| Type: | Labling Machine | Voltage: | 220V/380V |
|---|---|---|---|
| Weight: | 320kg | Key Selling Points: | Easy To Operate |
| Warranty Of Core Components: | 2 Years | Packaging Material: | Metal, Plastic, Wood |
| Driven Type: | Electric | Dimension(L*W*H): | 3000x1700x1500(mm) |
| Highlight: | Stainless Steel Filling Capping Labeling Machine,Bottle Filling Capping Labeling Machine,Automatic Filling Capping And Labelling Machine |
||
Product Description
Filling Capping Labeling Machine 304 Stainless Steel Fully Automatic For Bottle
Product Description:
World famous brand PLC and servo system, multifunctional man-machine interface operation production count, visual monitoring of parameter adjustment help function and fault display show function, can present many group labeling parameters, Change bottle no need resetting, Detect label length automatically.
Features:
1. The whole machine and spare parts use international standard SUS304 stainless steel imported alloy material. double anodic oxidation treatment, with high corrosion resistance and never rust, suit for any production environment.
2. German import labeling engine is optional, advanced self-adaption labeling control system, reduce and simplify operating and adjusting, improve efficiency, After change products or label, made simply adjustment is ok, do not have many requirements for worker skill.
3. Separate bottle device uses silica gel materials.keep bottles delivery to labeling part with the same distance.
4. Rolling label device can choose detachable belt or industrial synchronous belt.
Specification:
| Model | WD200 |
| Label objects size | Diameter:20-100mm;H:30-260mm |
| Label size | L:10-200mm;H:10-140mm |
| Labeling speed | 30-180pcs/min |
| Labeling accuracy | ±1.0mm |
| Label type | Adhesive sticker, transparent or opaque |
| Label roll diameter | Inner diameter:76 mm Outer diameter:350 mm(max) |
| Voltage | AC110/220/240V 1phase |
| Power | 1.6KW 50/60HZ |
| Air pressure | 0.6Mpa |
| Applicable Environment | Temperature:5-40Humidity 15-85%(No condensation) |
| Weight | 330kgs |
| Machine dimension | L2900*W1450*H1500mm |
| Remarks | can be customized as your requirements. |
Famous brand electrical parts:
| Item name | Brand |
| PLC | MITSUBISHI |
| Touch Screen | WEINVIEW |
| Inverter | DANFOSS |
| Servo motor | DELTA |
| Switch | DELTA |
| Optical | OMRON |
| Label Sensor | Leuze |
| Servo motor | DELTA |
Packing and Delivery :
Company Profile :
FAQ:
1. what services can we provide?
Accepted Delivery Terms: FOB,EXW；
Accepted Payment Currency:USD,EUR;
Accepted Payment Type: T/T,MoneyGram,Western Union;
Language Spoken:English,Chinese
2. I'm new in our industry,but I'm planing to set up a factory, what can I do?
We will design the most suitable proposal based on your actual situation, such as the daily production,raw material formula, factory layout, etc. Also we would like to introduce some excellent suppliers of raw materials, bottles,labels, etc if needed. After sales, engineer will be send to fields installation, training and commissioning.
3. How can you control the quality before delivery?
First, our component/spare parts providers test their products before they offer components to us.Besides, our quality control team will test machines performance or running speed before shipment. We would like to invite you come to our factory to verify machines yourself. If your schedule is busy, we wil take a video to record the testing procedure and send the video to you.
4. Are your machines difficult to operate? How do you teach us using the machine?
Our machines are fool-style operation design,very easy to operate.Besides,before delivery we will shoot instruction video to introduce machines'functions and to teach you how to use them.If needed engineers are available to come to your factory to help install machines, test machines and teach your staff to use the machines.
5. Can you make the machine according to buyer's request?
Yes, Most of our machines are customized design based on customer's requirements or situation.
