Filling Capping Labeling Machine Multifunctional Detergent Labeling Machine
Product Details:
| Place of Origin: | Guangdong |
| Brand Name: | Weidong |
| Certification: | CE&ISO9001 |
| Model Number: | WD-bl660 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | $4800~$5000/set |
| Packaging Details: | Wooden case |
| Delivery Time: | 5-7 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 30 set per month |
|
Detail Information |
|||
| Packaging Type: | Case | Application: | Beverage, Chemical, Commodity, Food, Machinery & Hardware,Medical, APPAREL,Textiles |
|---|---|---|---|
| Packaging Material: | Metal, Plastic, Wood | Driven Type: | Electric |
| Warranty Of Core Components: | 2 Years | Size: | 3000x1700x1500mm |
| Marketing Type: | Ordinary Product | Key Selling Points: | Easy To Operate |
| Highlight: | Antirust Two Side Labeling Machine,0.6Mpa Two Side Labeling Machine,Multifunctional Detergent Labeling Machine |
||
Product Description
Filling Capping Labeling Machine Multifunctional Detergent Labeling Machine
Product Description:
Double-sided automatic labeling machine is suited for round, flat, square, cone shape products in Cosmetic, food, pharmaceutical, and other light industries, labeling on one size one two sides all ok as client need.
Operation control system:
World famous brand PLC and servo system, multifunctional man-machine interface operation production count, visual monitoring of parameter adjustment help function and fault display show function, can present many group labeling parameters, Change bottle no need resetting, Detect label length automatically.
Optional:
&.Thermal transfer printer(TTO) or ink-jet coding is optional.
&.The turntable is optional if machine operated alone.
&.Detect Barcode or with label or-or function, rest label alarm function.
Technical Specification:
| Model | WD200 |
| Label objects size | Diameter:20-100mm;H:30-260mm |
| Label size | L:10-200mm;H:10-140mm |
| Labeling speed | 30-180pcs/min |
| Labeling accuracy | ±1.0mm |
| Label type | Adhesive sticker, transparent or opaque |
| Label roll diameter | Inner diameter:76 mm Outer diameter:350 mm(max) |
| Voltage | AC110/220/240V 1phase |
| Power | 1.6KW 50/60HZ |
| Air pressure | 0.6Mpa |
| Applicable Environment | Temperature:5-40Humidity 15-85%(No condensation) |
| Weight | 330kgs |
| Machine dimension | L2900*W1450*H1500mm |
| Remarks | can be customized as your requirements. |
The machine adopts famous brand component parts to keep the machine with high quality. but we are factory, so our price is competitive.we hope you will be our customer, and you will be satisfied with our product and service
