5-5000ml Horizontal Self-Suction Cosmetic Liquid Filling Machine
Product Details:
| Place of Origin: | Guangzhou,China |
| Brand Name: | Weidong |
| Certification: | CE&ISO9001 |
| Model Number: | GZJ-W150-5000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $359-880/a set |
| Packaging Details: | Packed in plastic and wooden case, seaworthy wooden case. Standard export wooden case packaging, fit for multiple handing and long distance marine shipping. |
| Delivery Time: | 5-8workday |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500 set/month |
|
Detail Information |
|||
| Type: | Filling Machine | Application: | Food, Beverage, Chemical,Cosmetic |
|---|---|---|---|
| Voltage: | 220v/50hz | Driven Type: | Pneumatic |
| Filling Range: | 10 -100ml | Filling Speed: | 10-30 Times/minute |
| Automatic Grade: | Semi-automatic | Machinery Capacity: | 12000BPH, 6000BPH |
| Product Name: | Cosmetic Liquid Filling Machine | Material: | SUS 304/316L |
Product Description
5-5000ml Horizontal Self-Suction Cosmetic Liquid Filling Machine
Cosmetic Liquid Filling Machine Basic Introduction
1. 5-5000ml Horizontal Self-Suction Cosmetic Liquid Filling Machine uses compressed air as power, by a precision pneumatic components constitute an automatic filling system, simple structure, reliable sensitive action, convenient adjustment.
2. For a variety of liquids, viscous fluids, cream, milk, butter materials such as liquid filling operations.
3. The semi automatic piston filling machine is a pharmaceutical, chemical, food, cosmetics and other industries ideal filling equipment. Humanized design more in line with the requirements of the modern enterprise.
Specifications
| Machine name | 5-5000ml Horizontal Self-Suction Cosmetic Liquid Filling Machine | |
| Model | GZJ-W150 | GZJ-W5000 |
| Metering methods | Piston Pump | Piston Pump |
| Mode of operation | Foot or automatic | Foot or automatic |
| container | Arbitrary shape | Arbitrary shape |
| Filling range | 10-100ml | 10-100ml |
| Filling speed | 10-30 times/minute | 10-30 times/minute |
| Filling precision | ≤2% | ≤2% |
| Air pressure | 0.4-0.6Mpa | 0.4-0.6Mpa |
| Voltage | 220v/50hz | 220v/50hz |
| Power | 20w | 20w |
| Dimension | 1250*340*340mm | 1050*500*1390mm |
| Weight | 27kg | 50kg |
Note: Due to the escalating changes piston filling machine, the above technical parameters for reference only, to prevail in kind, please understand!
Feature
1. The well-known brand pneumatic components, low failure rate, stable performance.
2. Using compressed air as power, highly secure, particularly suitable for use in explosion-proof requirements of environment.
3. And material contact parts are made of high quality stainless steel, meet the health requirements.
4. Filling volume and filling speed can be adjusted, high precision filling.
5. Configuring anti-drip filling head, to prevent dripping and stringing.
6. No replacement parts, you can quickly adjust the replacement of different shapes and sizes of bottles, applicability.
7. The main components are active connections, easy to disassemble and clean.
8. A pedal, jog and automatic transfer switch, according to the filling state switch freely.
Packaging & Shipping
All the products before delivery should be tested by assemble&debugging engineer, wiped up and cleaned,then wrapped by stretch film to protect it from moist. The precision part need to flexible package. In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory.
All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading&uploading, the upward mark will be posted on the wooden case.
Packaging details: Standard export packing, major products using export plywood case packing, small products use thick carton packing, ensure that the product packaging integrity and safety.
Shipping methods:
1. Shipping by sea(recommend big product or a lot of goods of the order)
2. By air
3. By express: TNT, EMS, DHL, FEDEX, UPS Etc.
